SC-1204™
Multi-use LTE CAT M1 tracker for global shipment visibility and compliance
1 of 2
The SC-1204 logs location and environmental conditions for assets traveling by road, air, or sea. LTE CAT M1 connectivity, ocean and flight modes, multiple onboard sensors, and flexible power options support shipment visibility, cargo monitoring, and compliance.
- LTE CAT M1 connectivity supports shipment visibility
- Ocean and flight modes support multimodal transportation
- Sensors monitor light, motion, pressure, temperature, and shock
- Rechargeable battery and external power options add flexibility
- Qi wireless charging simplifies device reuse
- Supports asset, cargo, pallet, and package monitoring
Product specifications
| Physical Design | |
|---|---|
| Dimensions | 142.7 × 82.7 × 17.7 mm (5.62 × 3.26 × 0.70 in) |
| Weight | 208 g (7.3 oz) |
| Cellular | |
|---|---|
| LTE Cat-M1 Bands | B1, B2, B3, B4, B5, B8, B12, B13, B28 |
| 2G Fallback Bands | B2, B3, B5, B8 |
| GNSS | |
|---|---|
| GNSS Constellations | GPS |
| Location Accuracy | GPS: 3-5 m; Wi-Fi: 100 m; Cellular: 500 m |
| Wireless Interfaces | |
|---|---|
| Bluetooth | BLE |
| Wi-Fi | 802.11b/g/n, 2.4 GHz |
| Power | |
|---|---|
| Battery Capacity | 3.7 V, 4000 mAh (14.8 Wh; 5.0 A rate) |
| Battery Chemistry | Lithium-ion (Li-ion) |
| Battery Type | Rechargeable internal backup battery |
| Battery Life | 15 days at 15-minute reporting |
| Operating Parameters | Qi wireless charging (approximately 8 hours); on/off button; charging/status indications |
| Environmental | |
|---|---|
| Operating and Storage Temperature | Operating: -10 to 50 C (14 to 122 F) Storage: -10 to 40 C (14 to 104 F) |
| Shock and Vibration | Shock and vibration resistant |
| Sensors | |
|---|---|
| Temperature Sensor | NIST traceable; typical accuracy +/-0.5 C (-30 to 60 C); configurable min/max thresholds |
| Shock Sensor | Dedicated 3-axis accelerometer; 16 G max; impact, drop and 90-degree tilt events |
| Light Sensor | Threshold on/off |
| Proximity Sensor | Supported through BLE proximity tags |
| I/O | |
|---|---|
| Digital Inputs | Digital I/O options; count not specified |
| Analog Inputs | Analog I/O options; count not specified |
| Status LEDs | Green on; red off; periodic green pulse while charging |
| Software Services | |
|---|---|
| Device Management | Manage, configure, and deploy OTA software updates to connected assets at scale |
| CalAmp Telematics Cloud | Stream telematics data into proprietary systems with flexible API integration |
| CalAmp Application | Fleet and asset management software for tracking, monitoring, and managing vehicles, equipment, drivers, assets, and cargo. |
| Certifications | |
|---|---|
| Certifications | FCC; CE; PTCRB; applicable carriers; Industry Canada; NOM |
