SC120

SC-1204

Multi-Use LTE CAT-M1 Smart Tracking Device for Visibility and Compliance
Software & Services
Highlights
Technical Specs
Related Products
Download PDF
Software & Services
The SC1204 is a tracking device engineered for logging location and environmental conditions. It is an ideal solution for tracking assets over the road, in flight and at sea.

Software and Services

  • SC iOn Platform
  • 24/7 Command Center Monitoring
  • API Platform Support

Networks

  • LTE Cat-M Cellular with Multi-Country Support
  • Wi-Fi Enabled
Highlights

Smart Tracking Device for Visibility and Compliance

Inventory

Features

  • Ocean & Flight Modes
  • Sensors for: Light, Motion, Pressure, Temperature and Shock Battery & External Power Options
Proof Of Delivery

Market Applications

  • Asset Tracking
  • Cargo Monitoring
  • Pallet- and Package-Monitoring
Technical Specs
Cellular/Network
Communication

Cellular: LTE CAT-M1 cellular with multi-country support

B1/B2/B3/B4/B5/B8/B12/B13/B28

Fallback to 2G

Bi-directional communications

Over-the-air adjustable reporting rate

Reporting rate: 1 min to 24 hour

Wi-Fi Enabled

2.4Ghz B/G/N

Location Accuracy
Wi-Fi

100 meters

Cellular

500 meters

GPS

3-5 meters

Certifications
Industry Certifications

FCC, CE, PTCRB, Applicable carriers Industry Canada, NOM

Power
Rechargeable li-ion battery
Qi wireless recharging (8 hr recharge time)
On/Off button
Green upon button press for on; Red upon button press for off
Green pulse (periodic) for charging
Battery Duration: 15 days @ 15 min reporting
Environmental
Temperature

-10º C to 50° C | 14º F to 122° F (operating)

-10º C to 40º C | 14º F to 104° F (storage)

Ocean & Flight Modes
Rugged Construction

Shock and vibration resistant

Physical/Design
Dimensions

5.62” x 3.3” x 0.7” (142.7 x 82.7 x 17.7 mm)

Weight

208g (7.3 oz)

Battery Pack
Battery Capacity

3.7V 4000mAh (14.8Wh, 5.0A rate)

Battery Technology

Lithium Ion

Sensors
BLE SC iOn Tags
Motion

Stationary/moving after stationary

Temperature

NIST Traceable

Accuracy +/- 0.5C type (-30C to 60C)

Min/Max Threshold (configurable)

Light

Threshold on/off

Pressure

Flight detection

Shock

Dedicated 3-axis accelerometer

16 G max

Impact

General shock event

Drop

Vertical drop above threshold

Tilt

90 degrees

Product Options
SC iOn Platform
24/7 Command Center Monitoring
API Platform Support
