ATU-1650MB™
Compact, rugged GPS asset tracker with multi-region connectivity
1 of 3
The CalAmp ATU-1650MB delivers accurate GPS tracking, long battery life, and rugged performance in a compact, discreet form factor. It supports standalone or dual-device operation, configurable reporting, and remote management through CalAmp Device Management for vehicle recovery and asset tracking.
- Up to seven years of battery life at one report per day
- Rugged IP66- and IP67-rated weatherproof design
- Multi-region connectivity for broad deployment flexibility
- Standalone or dual-device operating modes
- Bluetooth Low Energy 5.2 connectivity
- Remote management through CalAmp Device Management
Product specifications
| Physical Design | |
|---|---|
| Dimensions | 63.5 × 50.8 × 27.9 mm (2.50 × 2.00 × 1.10 in) |
| Weight | 106 g (3.7 oz) |
| Cellular | |
|---|---|
| LTE Cat-M1 Bands | B1, B2, B3, B4, B5, B8, B12*, B13, B18, B19, B20, B25*, B26, B27, B28, B66*, B85 |
| 2G Fallback Bands | B2, B3, B5, B8 |
| Cellular Data Support | SMS, UDP Packet Data |
| GNSS | |
|---|---|
| GNSS Constellations | GPS, GLONASS, Galileo, BeiDou |
| Tracking Sensitivity | -161 dBm |
| Acquisition Sensitivity | -145 dBm (cold start) |
| Location Accuracy | <2.5 CEP open sky |
| A-GPS Location Assistance Capable | Yes |
| Wireless Interfaces | |
|---|---|
| Bluetooth | BLE 5.2 |
| Vehicle & Interfaces | |
|---|---|
| Serial Interface | USB |
| Antennas & SIM | |
|---|---|
| Cellular Antenna | Internal |
| GPS / GNSS Antenna | Internal |
| SIM Access | Internal (4FF SIM) |
| Power | |
|---|---|
| Battery Capacity | 4400mAh |
| Battery Chemistry | Lithium manganese dioxide (LiMnO2) |
| Battery Life | One report per day: up to 7 years Four reports per day: up to 1.5 years Report every 5 minutes: up to 10 days |
| Environmental | |
|---|---|
| Operating and Storage Temperature | -25°C to +68°C (operating) |
| Humidity | +25°C to +60°C, 65% RH |
| Shock and Vibration | SAE J1455 |
| Electrostatic Discharge | IEC 61000-4-2, 4 kV |
| Ingress Protection Rating (IP) | IP66 & IP67 |
| I/O | |
|---|---|
| Serial Interface | USB: Internal debug & configuration |
| Edge Intelligence | |
|---|---|
| Firmware | EdgeCore |
| Edge Programming | PEG2 & EdgeApp SDK |
| On-Device Geofences | Locally stored geofence data for real-time geospatial processing |
| Buffered Messages | Up to 20,000 |
| Device Operating System | ThreadX RTOS |
| Software Services | |
|---|---|
| Device Management | Manage, configure, and deploy OTA software updates to connected assets at scale |
| CalAmp Telematics Cloud | Stream telematics data into proprietary systems with flexible API integration |
| CalAmp Application | Fleet and asset management software for tracking, monitoring, and managing vehicles, equipment, drivers, assets, and cargo. |
| Certifications | |
|---|---|
| Certifications | FCC, PTCRB, CE, CE Cybersecurity, ISED, RoHS 3, E-Mark, Applicable Carriers |
| Accessories | |
|---|---|
| Accessories | installation bracket sold separately |
* Band 12 is a superset of Band 17, Band 25 is a superset of Band 2, and Band 66 is a superset of Band 4.
** Battery life varies based on environmental conditions, installation orientation, update frequency, network availability, and any advanced configurations or optional BLE-enabled features.
